■ Relay type: electromagnetic

■ Contacts configuration: SPDT

■ Rated coil voltage: 12V DC

■ AC contacts rating @R (at resistance load): 16 A / 250 VAC

■ DC contacts rating @R (at resistance load):16 A / 30 VDC

■ Contact current: max.30A

■ Switched voltage: max 220V DC, max 400V AC

■ Relay variant: miniature

■ Mounting: PCB, socket

■ Coil resistance: 220Ω

■ Body dimensions: 29 x 12.4 x 25mm

■ Coil power consumption: 650mW

■ Operating temperature: -40...85°C

■ Relay series: 40.61

■ Contact material: AgNi

■ Terminal pitch: 5mm

■ Coil current: 55mA
